- Air pollution monitor for PM10, PM2.5 and O3 monitoring
- TÜV approved, Compliant with 2008/50/EC EN15267
- Nephelometric principle combined with virtual impactor
- Photometer in regulated heating chamber
- Alternating measuring of PM10 and PM2.5 wi
应用
- Air pollution monitor for PM10, PM2.5 and O3 monitoring
- TÜV approved, Compliant with 2008/50/EC EN15267
- Nephelometric principle combined with virtual impactor
- Photometer in regulated heating chamber
- Alternating measuring of PM10 and PM2.5 with adjustable interval
- Stainless steel housing, appearance size is 19 inches
*Optional: Derenda IOT cloud solution with online remote and monitoring
*Optional: TSP parameter
*Meteorological five parameters
|
Data storage capability：＞100000 |
Temperature:(-30-50)°C |
|
Humidity:(0-100)%RH |
Dehumidifying function: Automatic heating dehumidifying |
|
Dimensions (W x H x D):560×395×340mm |
Weight: 45kg |
|
O3 |
|
|
operational principle |
UV-absorption method, single-light path |
|
Measurement Range: (0-500)μg/m3 |
Resolution : 0.1μg/m3 |
|
Precision : ±2μg/m3 |
Detection limit: 2.0μg/m3 |
|
Baselinedrift: <3μg/m3/day<6μg/m3/year |
Sensitivity drift: <1%/day，<3%/year |
|
Data average: 10s,1 min,5 min,1 h |
Measurement time and frequency: 2s,0.5 Hz |
|
Emperature and pressure calibration: Standard features |
Measurement unit: ppb、μg/m3 |
|
Flow: Minimum 0.6 L/min; maximum 1.5 L/min; rated 1 L/ min |
|
|
PM2.5&PM10 |
|
|
operational principle |
Laser light scattering |
|
Flow: 3.3L/min |
Flow range: (0-2500)μg/m3 |
|
Resolution: 0.1μg/m3 |
|
